Compatibility
Which ute canopies and service bodies do Wedgetail racks fit?
Short answer
Wedgetail makes canopy kits for ARB, EGR Gen 2, Maxliner Venture, RSI Evo, Utemaster Centurion and Ascent canopies and service body kits for Caddy Storage, CSM and Mode, plus Oval Steel canopy racks. If a canopy is not on this list, Wedgetail does not fit it. Wedgetail platforms are rated 100 or 150 kg dynamic (350 or 525 kg static) and hold that rating 100% off-road, and on a canopy the lower of the rack rating and the canopy maker's roof rating applies.
Facts from Wedgetail product data, updated .
- Canopies fitted
- ARB, EGR Gen 2, Maxliner Venture, RSI Evo, Utemaster Centurion, Ascent
- Service bodies fitted
- Caddy Storage, CSM, Mode
- Not on the list
- Not fitted
- Platform ratings
- 100 or 150 kg dynamic, 100% off-road
| Make | Type | Solutions listed |
|---|---|---|
| ARB | Canopy | 18 |
| EGR Gen 2 | Canopy | 6 |
| Maxliner Venture | Canopy | 3 |
| RSI Evo | Canopy | Custom fit: contact Wedgetail |
| Utemaster Centurion | Canopy | 1 |
| Ascent | Canopy | 11 |
| Caddy Storage | Service body | 30 |
| CSM | Service body | Custom fit: contact Wedgetail |
| Mode | Service body | Custom fit: contact Wedgetail |
Which Wedgetail range fits each canopy
Canopy kits come in the Wedgetail Adventure, Wedgetail Trade and Oval Steel ranges. Service body kits come in Commercial Max and Wedgetail Trade. Each kit is made for one canopy or body on one ute, so the vehicle, cab and canopy all have to match the listing.
| Canopy or body | Wedgetail kits | Fit method | Example |
|---|---|---|---|
| ARB (Classic) | Wedgetail Adventure for the Isuzu D-MAX (2012 to 2020); Oval Steel ARB Classic combination racks for the Ranger, HiLux, Triton, Navara, Colorado, D-MAX, BT-50 and Amarok | Rail utilising OEM fixtures; drilled rail mount | Adventure kit, D-MAX; Oval Steel, Ranger 2022 on |
| Ascent | Wedgetail Adventure for the Ford Ranger (2022 on); Oval Steel Ascent combination racks for the Ranger, HiLux, Triton, Colorado, D-MAX, BT-50 and Amarok | Bolted to OE holes; drilled rail mount; rail utilising OEM fixtures | Adventure kit, Ranger; Oval Steel, HiLux 2015 to 2025 |
| EGR Gen 2 | Wedgetail Adventure and Wedgetail Trade for the Isuzu D-MAX and Mazda BT-50 (2020 on) | Fixed points | Adventure kit, D-MAX; Trade kit, D-MAX |
| Maxliner Venture | Wedgetail Adventure for the Isuzu D-MAX and Mazda BT-50 (2020 on) and Toyota HiLux (2015 to 2025) | Bolted to OE holes | D-MAX Maxliner Venture kit |
| Utemaster Centurion | Wedgetail Adventure dual cab kit | Rail utilising OEM fixtures | Utemaster Centurion kit |
| RSI Evo | Custom fit: made to order | Made for your ute | Contact Wedgetail |
| Caddy Storage service body | Commercial Max for the Ranger, Colorado, D-MAX, BT-50, Triton, Navara, HiLux and Amarok; Wedgetail Trade service body combination kits for dual and extra cabs | Bolts to OE mount; bolted to OE holes | Commercial Max, Ranger 2022 on; Trade kit, dual cab; Trade kit, extra cab |
| CSM and Mode service bodies | Custom fit: made to order | Made for your ute | Contact Wedgetail |
If your canopy is not on the list
Wedgetail does not fit it. A canopy kit is built around the mounting points of one canopy make, so a kit for an ARB or EGR Gen 2 canopy is not a fit for a different steel, aluminium or fibreglass canopy that looks similar. If you are choosing a canopy now and want a Wedgetail on it, pick one of the makes above.
If you keep a canopy Wedgetail does not fit, the alternative is a rack on the cab roof. See canopy mount or cab mount for how the two compare.
Which load limit applies on a canopy
- The rack rating: one dynamic rating per Wedgetail solution, held 100% off-road, with static at 3.5 x dynamic.
- The canopy maker's roof rating: the canopy or service body maker sets its own roof limit and any support it needs under a roof load.
- The lower figure applies. Add the rack, the accessories and the load, and keep the total within both.
For a rooftop tent on a canopy, the tent on the move goes against the dynamic figures and the tent plus occupants parked goes against the static figures, on the rack and the canopy alike.
Find the kit for your ute
Start with your ute: the Ford Ranger, Toyota HiLux, Isuzu D-MAX, Mazda BT-50, Mitsubishi Triton, Nissan Navara and Volkswagen Amarok guides list every Wedgetail option by generation. The canopy guides for the HiLux, D-MAX, BT-50 and Ranger cover canopy fitments only. Every one of the 134 Wedgetail stockists sells and fits, and the factory in Bayswater VIC fits racks on site.
Video
Questions people ask
Which canopies can a Wedgetail roof rack mount to?
ARB, EGR Gen 2, Maxliner Venture, RSI Evo, Utemaster Centurion and Ascent canopies, and Caddy Storage, CSM and Mode service bodies. A canopy not on that list is not fitted.
Does Wedgetail make a roof rack for an ARB canopy?
Yes. There is a Wedgetail Adventure kit for the ARB canopy on the 2012 to 2020 Isuzu D-MAX, and Oval Steel ARB Classic and Ascent combination racks for the Ranger, HiLux, Triton, Navara, Colorado, D-MAX, BT-50 and Amarok.
Will a Wedgetail fit my steel or fibreglass canopy if the make is not listed?
No. Kits are made for the listed makes only. With an unlisted canopy, fit a cab roof rack instead.
What load can I carry on a canopy rack?
The lower of the rack rating and the canopy maker's roof rating. Wedgetail platforms are rated 100 or 150 kg dynamic (350 or 525 kg static), 100% off-road, and the rating is listed per solution.
Can I put a rooftop tent on a canopy rack?
Yes, on a platform kit, if the tent is within the dynamic figures and the tent plus occupants is within the static figures of both the rack and the canopy. Platforms are the Wedgetail rooftop tent base.
Does Wedgetail fit Caddy Storage service bodies?
Yes. Commercial Max platforms suit Caddy Storage service bodies on the Ranger, Colorado, D-MAX, BT-50, Triton, Navara, HiLux and Amarok, and Wedgetail Trade makes service body combination kits for dual and extra cabs.
What do I need to tell a stockist to get the right canopy kit?
The ute make, model, year and cab, and the canopy or service body make and model. With those, the stockist can match the kit, and every stockist sells and fits Wedgetail.
